Conch

01.191A03000

le unique narrow side face ring design breaks through the traditional way ofexpression . rich color matching , to meet the various theme space applications.
  • A03 Conch
1 1

Specification

  • 01.191A03000
  • Power：10W / 12W
  • Installation method：Recessed
  • Cut out：φ65mm
  • Dimming：Non-DIM 、TRIAC、0/1-10V、DALI、 BLE 、ZIGBEE
  • Frequency：50/60HZ
  • LED：COB
  • Lumen：78lm/w
  • CCT：2700K/3000K/3500K/4000K
  • CRI：≥90
  • SDCM：＜3
  • Adjustibility：NO
  • Light distribution：Direct
  • UGR：＜19
  • Beam angle：18°/22°/32°
  • Protection class：IP20
  • Material：Aluminum
  • Environment temperature：-25°C~50°C
  • LED life Time：  35,000h~ 50,000h – L80
Se komplette oplysninger
Product icon

Download

A03 Conch
A03 Conch
A03 Conch
A03 Conch
A03 Conch

BEAM ANGLE

A03 Conch
A03 Conch
A03 Conch
18°
22°
32°

Applicable Instructions for 18° Illumination

This is an angle suitable for basic lighting， It is used in general lighting scenarios, and the application scenarios are: office area, store, villa, residence, etc., the same type of life scene.
