A01 Gyro 20W Magnetic LED Light

07.043A01000

Magnetic lighting system as a new generation of lighting solutions, through the track layout consistent with the decoration style, lamps in the form of modules, convenient disassembly, flexible movement and other features of free combination. It not only attention to both the key lighting and basic lighting functions. Thoroughly change before need to cut hole, wiring and other troublesome installation way, totally accord with the trend of current minimalism style popularity.
1 1

Specification

  • 07.043A01000
  • Power：20W
  • Installation method：Magnetic
  • Cut out：NO
  • Dimming：Non-DIM  、 0/1-10V 、DALI 、BLE 、 ZIGBEE
  • Frequency：50/60HZ
  • LED：COB
  • Lumen：104lm/w
  • CCT：2700K/3000K/3500K/4000K/2700K-6000K
  • CRI：≥90
  • SDCM：＜3
  • Adjustibility：NO
  • Light distribution：Direct
  • Beam angle：18°/25°/36°/60°
  • Protection class：IP20
  • Material：Aluminum
  • Environment temperature：-20°C~40°C
  • LED life Time：  35,000h~ 50,000h – L80
Se komplette oplysninger
Product icon

Download

A01 Gyro
A01 Gyro
A01 Gyro
A01 Gyro
A01 Gyro
A01 Gyro
A01 Gyro

BEAM ANGLE

A01 Gyro
A01 Gyro
A01 Gyro
19°
23°
31°

Applicable Instructions for 19° Illumination

This is an angle suitable for basic lighting， It is used in general lighting scenarios, and the application scenarios are: office area, store, villa, residence, etc., the same type of life scene.
